Flexbroidery Patches

DESCRIPTION:
Our state-of-the-art emblem solutions are perfect for a wide range of applications. From corporate branding to personal projects, Flexbroidery emblems are built to last, making them perfect for uniforms, accessories, and various types of apparel.

EMBLEM SIZE LIMITS:
Minimum: 0.5” x 0.5”
Maximum: 3.75” x 4”

COLORS:
This product accepts RGB, CMYK, and Pantone (PMS) color codes. Please note that all submitted colors will be converted to RGB, which may result in slight variations from the original PMS or CMYK colors. Neon, glitter, and reflective colors are not available for printing.

BACKING:
LOW MELT - This backing is more commonly used on wearables and
applied with a heat press.

LIMITATIONSLow Melt: Since the product is applied with heat, it is not recommended for use on materials that may be heat sensitive (ex. some nylons, silk, some plastics, leather, wool, fleece, etc.) Not recommended for weather treated materials, due to chemicals used that do not allow the emblems to adhere properly.

DESIGNS
Floating elements: minimum 1.5mm / maximum 8mm
Non-floating elements: minimum 1.1mm / maximum 8mm
Text minimum: 6mm H
No ® mark allowed
100% color match not guaranteed
Note! Please refrain from using small details. Our specialized artist will determine what is feasible

ELECTRONIC PROOF
1 Day

PHYSICAL SAMPLE (WITH MOLD INCLUDED)
2 Days

PRODUCTION TIME
Up to 500pcs: 5 days
1 additional day for every 500pcs

Transit time not included.

WASHING INFORMATION
Flexbroidery™ emblems will withstand at least 25 domestic washing
machine cycles at 104° F max.

SHELF LIFE
1-year shelf life before applying (room temperature controlled
environment).

SET-UP CHARGES
One-time mold charge and artwork fee.

Note: TK Patches encourages our clients to test applications of our products unto their garments. TK Patches is not responsible for damages resulting from washing and laundering of any product purchased.

LOW MELT BACKING WITH A 360 IQ™ HAT HEAT PRESS - HATS

• Top Temperature: 275°-285° F
• BottomTemperature: 315°-320° F
• Pressure: 50-70 PSI
• Preheat: N/A
• Dwell Time: 15-18 seconds
• Instructions: Place hat on heat press, leaving out the inner layer of the cap. Use a FlexStyle® Silicone Pad to protect the patch.

LOW MELT BACKING WITH TOP HEAT & BOTTOM HEAT - GARMENTS

• Top Temperature: 275°-285° F
• BottomTemperature: 270°-280° F
• Pressure: 50-70 PSI
• Preheat: N/A
• Dwell Time: 15-18 seconds
• Instructions: Place patch on desired location and secure it in place with Thermal Tape. . Use a FlexStyle® Silicone Pad to protect the patch.

LOW MELT BACKING WITH A TOP HEAT PRESS - GARMENTS

• Temperature: 355°-365° F
• Pressure: 40-50 PSI
• Preheat: 15-20 seconds
• Dwell Time: 15-20 seconds
• Instructions: Place patch on desired location and secure it in place with Thermal Tape. . Use a FlexStyle® Silicone Pad to protect the patch.

DISCLAIMER
TK Patches recommends testing the best combination of heat seal parameters before application. TK Patches is not liable for any damages to garments during the application process.

PRICING

Using the drop-downs above, you can find the approximate price per item, based on the emblem size and quantity ordered.

To determine the size of your emblem, use the following formula:
Size = Width + Height / 2

PRICE INCLUDES

• Low melt backing

ELECTRONIC PROOF

A digital sample via email is available in 48 hours. Edits are allowed.

SET-UP CHARGES

One-time mold charge and artwork fees

• Electronic Simulation: $25
• Mold: $60

Production Time

Samples will take 2 days plus shipping. Production time will take 5 days plus shipping on an order up to 500 pieces. Add 1 day per 500 pieces.

NOTE: All turnaround times are subject to change. Larger orders may result in additional business days for production. Orders received after the cut-off time will be considered as received the next working day.
